AS STANDARD

• Easy to assemble
• 4-section steel slats platform base L=200 cm
• Available in two widths: 120/140 cm
• All metal work is powder coated in RAL 9023 (pearl dark grey)
• Electrically operated back rest to 70° and knee break function to 30°
• Mechanical height adjustment of footrest in 5 position
• Electrically operated height adjustment 270-695 mm, stroke 425 mm
• 4 x 100 mm individually lockable castors
• Full wood cover panel
• 24 Volt motor system
• Emergency battery 9 V powered lowering is standard in  case of mains failure
• Handset with single fault safety and locking device
• In compliance with IEC 60601-2-52
• Protection class IPX4
• Max. Patientweight: 300 KG
• Safety working load: 380 KG
• Superb stability through hooks

• AS AN OPTION

  • Beds extension 20 cm (8”)
  • Electrically operated Trendelenburg-/Anti-trendelenburg function
  • Monkey pole with triangle grip
  • Aluminium side rails available in 2 versions: 2 or 3 siderail system
  • Side guards beech décor with safety locking
  • Clip-on tray
  • Underbedlight
  • Reading lamp
  • Also available for a patient weight of 400 kg and 500 kg
  • Side rails bumper
